Case Report

A radiologically atypical case of an ampullary neuroendocrine tumor
Jagir Yeshwante1, Maunil Bhuta1, Ashwini Sankhe2, Jernail Singh Bava3, Anagha Joshi4, Tilak Dedhia1
1Resident, Department of Radiology, LTMMC & LTMGH - Sion, Mumbai Maharashtra, India.
2Assistant Professor, Department of Radiology, LTMMC & LTMGH - Sion, Mumbai Maharashtra, India.
3Professor - Addl, Department of Radiology, LTMMC & LTMGH - Sion, Mumbai, Maharashtra, India.
4Professor, Department of Radiology, LTMMC & LTMGH - Sion, Mumbai, Maharashtra, India.

Article ID: 100029IJHPDJY2015
doi:10.5348/ijhpd-2015-29-CR-4

Address correspondence to:
Jagir Deepak Yeshwante
Resident, Department of Radiology, LTMMC & LTMGH - Sion
Mumbai Maharashtra
India
B-401, Ved Om Shanti CHS, Oppositejainmandir, Shanti Nagar, Dombivali (east) - 421201
Phone: 8879099870

Access full text article on other devices

  Access PDF of article on other devices

[HTML Abstract]   [PDF Full Text] [Print This Article]
[Similar article in Pumed] [Similar article in Google Scholar]

How to cite this article:
Yeshwante J, Bhuta M, Sankhe A, Bava JS, Joshi A, Dedhia T. A radiologically atypical case of an ampullary neuroendocrine tumor. Int J Hepatobiliary Pancreat Dis 2015;5:17–21.


Abstract
Ampullary neuroendocrine tumors (ANETs) are rare tumors which show characteristic CT features. We present a case of a 42-year-old female, in which the CT features of an ampullary tumor were atypical for a neuroendocrine tumor but was confirmed on histopathology and immunohistochemistry as an NET. The uniqueness of our case was that the lesion showed mild enhancement in the arterial phase which was persistent in the venous phase with wash out in the delayed phase

Keywords: Ampullary region, Double duct sign, Neuroendocrine tumor


Introduction

Neuroendocrine tumors are neoplasms that arise from cells of the endocrine and nervous systems. Many are benign, while some are malignant. These tumors are most commonly found in the small intestine, with the most common subtype being carcinoid tumors. Pancreas, lungs, etc. are other sites where these tumors are found [1].

The ultrasonography of the patient was done using a 6 Hz probe. The computed tomography (CT) scan was done on a 64 slice multi-detector CT scanner. A triple phase CT scan was done by intravenous administration of 100 ml of contrast medium at a rate of 3 ml/s with a monophasic rate of injection. Arterial phase scanning was started after a delay of 23 s and portal venous scanning after a delay of 60 s. The 1 mm and 5 mm thick sections were acquired with subsequent coronal reconstruction.


Case Report

A 42-year-old female presented to the surgery OPD with complaints of weight loss with episodic pain in abdomen, yellowish discoloration of the eyes, generalized itching, vomiting since four months. On examination, mild tender hepatomegaly was noted and a clinical diagnosis of obstructive jaundice was made.

For further evaluation, an ultrasonography (USG) of the abdomen was advised, which revealed (Figure 1A):

  • a small hypoechoic mass, in the peri-ampullary region with central vascularity.
  • mild central and peripheral intra-hepatic biliary radicle dilatation.
  • dilatation of the Common Bile Duct and Pancreatic duct ("Double Duct Sign")
  • mild hepatomegaly with a normal gallbladder.

For further evaluation and extensions of the lesion, a CT scan of the abdomen was performed which revealed (Figure 1B-D):

  • a well-defined 24x23x22 mm sized, hypodense mass lesion showing mild arterial phase enhancement which persisted on venous phase in the peri-ampullary region, projecting into the lumen of 2nd part of duodenum with no adjacent extension or invasion.
  • mild central and peripheral intra-hepatic biliary radicle dilatation.
  • dilatation of the common bile duct and pancreatic duct ("Double Duct Sign")
  • mild hepatomegaly with a normal gallbladder.

Radiologically, after USG and CT correlation, a diagnosis of a peri-ampullary neoplasm was made. Esophagogastroduodenoscopy guided biopsy was performed.

Esophagogastroduodenoscopy revealed presence of a small sessile, fleshy mass in the peri-ampullary region jutting into the 2nd portion of duodenum (Figure 1E). A tissue biopsy was taken.

Histopathological (Figure 1F) and Immuno-histochemistry report suggested the diagnosis of a low grade neuroendocrine tumor (G1 – WHO classification) as the tumor cells expressed cytokeratin, synaptophysin and chromogranin.


Cursor on image to zoom/Click text to open image
Figure 1: (A) Ultrasonography (6 Hz probe) showing the ampullary mass with vascularity within (red arrow), (B) Computed tomography (CT) scan (axial – arterial phase) showing mild enhancement of the ampullary mass (red arrow), (C) Computed tomography (CT) scan (axial – venous phase) showing mild enhancement of the ampullary mass (red arrow), (D) Computed tomography (CT) scan (coronal–venous phase) dilated common bile duct (red arrow) and dilated pancreatic duct (orange arrow): Double Duct Sign, (E) Esophagogastroduodenoscopy showing the ampullary mass, (F) Histopathological image of the mass lesion showing monomorphic population of small round cells.



Discussion

Neuroendocrine tumors (NETs) are a large group of neoplasms with a wide spectrum of clinical, imaging, and pathologic characteristics. Imaging features of NETs can be challenging, and a multitude of imaging modalities may be required for accurate diagnosis. Accurate interpretation of the imaging findings is important to facilitate diagnosis and contribute to patient management.

Pancreatic neuroendocrine tumors, also known as NETs, are rare tumors arising from a putative common precursor, the APUD cell (amine precursor uptake and decarboxylation). These cells are of common embryological origin from the ectodermal ridge. These neuroendocrine tumors are histologically closely related to certain other neuroendocrine tumors like pheochromocytoma and medullary carcinoma of the thyroid. These tumors may or may not synthesize and secrete hormones, out of which the functioning tumors are those in which hormone secretion by the tumor results in a clinical syndrome. Non-functioning tumors are those in which either there is hormone secretion with no recognizable clinical features or no hormone secretion at all. Functioning tumors usually present early, due to the clinical symptoms, and pose a challenge for the radiologist [2].

Ampullary neuroendocrine tumor (ANET) are rare tumors, accounting for less than 1% of all gastrointestinal neuroendocrine tumors and less than 2% of all tumors of ampullary region [2] [3].

Histologically, although ANETs are similar to neuroendocrine tumors arising from other parts of gastrointestinal tract, they have distinct immunohistochemical features. Immunohistochemical staining is the main diagnostic method for these tumors, and ANET stain positively with chromogranin A and synaptophysin in majority of the cases [3] [4].

According to the International Classification of Diseases of Oncology, published by the World Health Organization (WHO), the ampulla has been designated a site specific code "241" and neuroendocrine tumors are given specific codes: neuroendocrine not otherwise specified (8246); small cell neuroendocrine carcinoma (8041); and large cell neuroendocrine carcinoma (8013) [4].

Radiologically, on ultrasonography, the tumor appearance is of a well-defined round mass, which is homogeneously hypoechoic in relation to the pancreas, and vascular on Doppler imaging. There may be a hyperechoic lesion or focal distortion of the pancreatic parenchyma, which may help in detecting the lesion, particularly in younger patients where the tumors tend to be less conspicuous due to the generally lower echogenicity of the pancreas. The use of enhancement pattern of these tumors using Ultrasound contrast agents, is currently under investigation. [5]

Functioning tumors are generally small, with low inherent contrast between the tumor and surrounding pancreas. Majority of islet cell tumors are hypervascular and will be best seen after intravenous injection of contrast. However, the best phase for the demonstration of these hyperattenuating small lesions is unclear [6][7][8]. Narrow window settings may help to improve detection. In our case, the lesion was well detected in the venous phase.

Insulinomas can be hypovascular, cystic and hypodense to the surrounding pancreas. [9]. Cystic pancreatic endocrine tumors are usually benign and non-functioning. It is difficult to differentiate them from other cystic pancreatic neoplasms on imaging alone [9]. In patients with a suspected gastrinoma, the imaging emphasis should be given to the 'gastrinoma triangle'

Large tumors are likely to be non-functioning with central necrosis and are more likely to be malignant. The features which are associated with malignancy include necrosis, large size, infiltration of the surrounding structures and calcification [10] .


Conclusion

The uniqueness of our case was that the lesion showed mild enhancement in the arterial phase which was persistent in the venous phase with wash out in the delayed phase. These features were atypical for ANET, which was later confirmed on histopathology and immunohistochemistry.
